ER-S3002 Warm white waterproof lamp
Architectural / landscape
PRODUCT DETAILS
All-aluminum structure, no fan, depending on the nature of aluminum alloy radiator cooling, absolutely silent mode design, modeling lightweight fashion, easy to install. Single 30W warm white LED light source, the light beam angle of 750, making it ideal for lighting small theatrical performances, background staining, dance halls, bars, landscape lighting and other places of choice. In addition to DMX512 signal but also have a strong RDM control technology.
Optics
LED type: single 30W warm white LED;
Light beam angle: 750;
Average life expectancy: ≥50,000H;
Colour
Color temperature: 3200K;
effect
4 kinds of built-in programs to choose from;
Fast electronic strobe: 1 ~ 25 Hz;
Dimming mode: eight kinds;
Control and Programming
Control channel: two kinds of channel mode (1/3);
Protocol: standard DMX512 protocol, RDM protocol;
Data Connection: waterproof three core wire port XLR input / output;
Display: 0802LCD display operation panel;
software
Optics
LED type: single 30W warm white LED;
Light beam angle: 750;
Average life expectancy: ≥50,000H;
Colour
Color temperature: 3200K;
effect
4 kinds of built-in programs to choose from;
Fast electronic strobe: 1 ~ 25 Hz;
Dimming mode: eight kinds;
Control and Programming
Control channel: two kinds of channel mode (1/3);
Protocol: standard DMX512 protocol, RDM protocol;
Data Connection: waterproof three core wire port XLR input / output;
Display: 0802LCD display operation panel;
software
Software upgrade: update software via DMX signal easily and quickly upgrade;
Intelligent temperature protection to ensure the LED life;
Light structure
Aluminum structure;
Power and power
Input voltage: AC 100V ~ 240V, 50 / 60Hz;
Rated power: 35W;
other
Protection class: IP 65;
Working environment: -15 ℃ ~ 45 ℃;
size and weight
Lamp Size: 204mm * 145mm * 203mm;
NW: 2.4kgs;
Intelligent temperature protection to ensure the LED life;
Light structure
Aluminum structure;
Power and power
Input voltage: AC 100V ~ 240V, 50 / 60Hz;
Rated power: 35W;
other
Protection class: IP 65;
Working environment: -15 ℃ ~ 45 ℃;
size and weight
Lamp Size: 204mm * 145mm * 203mm;
NW: 2.4kgs;
