E-B24030 Triple strip lights
Entertainment Lighting
PRODUCT DETAILS
Using eight triple RGB lamp beads 30W as the light source, the light beam angle of 600, each light source can be controlled individually, in combinations of three-dimensional space projected dynamic graphics, large areas of color rendering, can produce very bright lights graphics effect. In addition to DMX control has a powerful RDM, Art-Net, Kling-Net and other network control technology.
Optics
LED Type: 30W single triple RGB lamp beads;
Light beam angle: 600;
Average life expectancy: ≥50,000H;
Colour
Uniform RGB color mixing system and rainbow effect;
Create unlimited dynamic, unlimited color changes;
effect
13 kinds of built-in programs to choose from a variety of graphics;
Fast electronic strobe: 1 ~ 25 Hz;
Dimming mode: two kinds;
Dimming curve: four kinds;
Control and Programming
Control channel: eight kinds of channel mode (3/4/5/6/12/24/27/32);
Protocol: standard DMX512 protocol, RDM protocol;
Data Connection: Three core / pentandra XLR input / output;
Display: 1602A LCD display operation panel;
software
Optics
LED Type: 30W single triple RGB lamp beads;
Light beam angle: 600;
Average life expectancy: ≥50,000H;
Colour
Uniform RGB color mixing system and rainbow effect;
Create unlimited dynamic, unlimited color changes;
effect
13 kinds of built-in programs to choose from a variety of graphics;
Fast electronic strobe: 1 ~ 25 Hz;
Dimming mode: two kinds;
Dimming curve: four kinds;
Control and Programming
Control channel: eight kinds of channel mode (3/4/5/6/12/24/27/32);
Protocol: standard DMX512 protocol, RDM protocol;
Data Connection: Three core / pentandra XLR input / output;
Display: 1602A LCD display operation panel;
software
Software upgrade: update software via DMX signal easily and quickly upgrade;
Quiet fan, intelligent speed;
Intelligent temperature protection to ensure the LED life;
Light structure
Aluminum structure;
Power and power
Input voltage: AC 100V ~ 240V, 50 / 60Hz;
Rated power: 250W;
other
Degree of protection: IP 20;
Working environment: -15 ℃ ~ 45 ℃;
size and weight
Lamp Size: 880mm * 155mm * 173mm;
NW: 8.3kgs;
Quiet fan, intelligent speed;
Intelligent temperature protection to ensure the LED life;
Light structure
Aluminum structure;
Power and power
Input voltage: AC 100V ~ 240V, 50 / 60Hz;
Rated power: 250W;
other
Degree of protection: IP 20;
Working environment: -15 ℃ ~ 45 ℃;
size and weight
Lamp Size: 880mm * 155mm * 173mm;
NW: 8.3kgs;
